Vehicle Pro XXL Ultra-Wide – Up to 33 Ft Wide

VThe Vehicle Pro XXL Ultra-Wide Barrier Gate is designed for extra-wide vehicle entrances where a standard parking barrier is not sufficient. With barrier openings up to approximately 33 feet (10.0 m), it is suited for wide commercial entrances, freight facilities, company grounds, industrial properties, ports and other locations where a single barrier must control a large vehicle opening.

The system combines a heavy-duty barrier cabinet, powered drive system and modular control technology for demanding vehicle-access applications. Opening and closing times can be independently selected at approximately 8, 10 or 12 seconds, allowing operation to be matched to the entrance layout and traffic requirements. The control system provides five expansion slots for functions such as Ethernet communication, radio control and parking-space counting, while inputs and outputs can be individually configured.

For locations requiring additional perimeter control, the barrier can be equipped with an optional security arm skirt and climb-over prevention, helping provide a more substantial physical and visual barrier across exceptionally wide entrances. The system is particularly well suited to freight forwarders, industrial and company grounds, port facilities and other wide or multi-lane entrances.

The Vehicle Pro XXL should be considered an automatic vehicle-access barrier, not automatically a crash-rated hostile-vehicle barrier. Where deliberate vehicle impact protection is required, the project should be evaluated for a separately engineered and tested vehicle-mitigation system.

Technical Specifications

Maximum Barrier Width: Up to 33 ft / 10.0 m
Available Wide-Opening Class: Up to approximately 33 ft
Opening Time: Selectable 8, 10 or 12 seconds
Closing Time: Selectable 8, 10 or 12 seconds
Control System: Modular and expandable
Expansion: Five plug-in module positions
Inputs / Outputs: Individually configurable
Optional Security Feature: Security arm skirt with climb-over prevention
Typical Applications: Freight entrances, company grounds, ports, industrial properties and wide or multi-lane entrances
