Automatic Bollards - "Commercial"

The Automatic Bollards – Commercial provide advanced vehicle access control and perimeter protection for critical and restricted areas. Designed for demanding security applications, these retractable hydraulic bollards help prevent unauthorized vehicles from entering protected areas while allowing controlled access for authorized traffic.

Built for high-frequency use, the automatic bollards are well suited for government facilities, commercial properties, critical infrastructure, transportation facilities, restricted entrances, and other locations where reliable vehicle security is essential.

High-Security Vehicle Protection

The automatic bollards are performance certified to PAS 68 and IWA 14-1 standards. In a dual-bollard installation, the system is capable of stopping a 7,500 kg truck traveling at up to 48 km/h.

This makes the system an effective choice for protecting vehicle entrances and controlling access to restricted or security-sensitive areas.

Hydraulic Automatic Operation

The retractable bollards use an integrated hydraulic control system for reliable operation and frequent cycling. The hydraulic system is incorporated into the bollard assembly, helping simplify the overall installation while providing dependable performance.

A built-in gentle-stop function helps control the bollard as it reaches its lower limit, reducing impact during operation.

Security and Tamper Protection

The bollard is designed with an anti-tamper head and protected security lock to help prevent unauthorized lowering of the bollard. This added protection helps maintain the barrier when access has not been authorized.

The system can be incorporated into a vehicle access control system to coordinate bollard operation with authorized entry.

Simplified Maintenance

The automatic bollards are designed for simplified servicing, with maintenance that can be performed by a single person. The integrated hydraulic design helps reduce the complexity associated with separate hydraulic equipment.

A shallow-mount installation design is also available within the product family, making the system suitable for sites where excavation depth is limited.

Automatic and Fixed Configurations

The product family includes both automatic retractable and fixed bollard configurations. The fixed version does not require power or wiring and can be installed alongside automatic units to create a consistent protected perimeter.

The fixed and retractable bollards have a matching design, making them well suited for mixed installations where some locations require controlled vehicle access and others require permanent protection.

Applications

Automatic Bollards – High Security are ideal for:

• Critical infrastructure
• Government facilities
• Transportation facilities
• Commercial properties
• Restricted vehicle entrances
• High-security perimeter protection
• Industrial facilities
• Controlled-access areas
• Sites requiring frequent vehicle access control

Specifications

• Bollard Diameter: 275 mm
• Cylinder Height: 800 mm
• Operation: Hydraulic automatic
• Security Standards: PAS 68 and IWA 14-1
• Impact Protection: 7,500 kg truck at up to 48 km/h in dual installation
• Maximum Power: 575 W
• Hydraulic System: Integrated
• Use: High-frequency operation
• Security: Anti-tamper head and protected security lock
• Installation: Retractable or fixed configurations available
