Optical Turnstile, Hi-Panel, Swing Gate

Need to fit a narrow passageway?  This elegant optical turnstile with clear bi-parting barriers has thin cabinets. Designed in Scandinavia but made in the USA, these are top of the line turnstiles.

Clear bi-parting barrier panels may be ordered in 39.4", 47.2", or 70.9" height.  The glass is .39 thick tempered glass, or optional clear acrylic.

Its slim cabinets are only 6.7" wide for standard or ADA lanes.  Cabinet lengths come in 59.1" or longer 75.8".  The glass in the cabinets' centers are .53" thick tempered glass.  The cabinet lids can be anodized aluminum black or silver.  Other options are available.

The compact floor footprint allows more lanes to fit in a smaller space. Center expansion cabinets have the same dimensions as end cabinets, allowing space saving multi-lane configurations whether providing standard lane width of 28" passage width or an ADA-compliant 36" passage widths.

When an authorized user presents a valid credential, the barriers open quickly and precisely, moving 'away' from the user in the same direction the user is travelling.

Add the option for our remote touchscreen or desktop controller for a guard's desk to control the turnstiles remotely.

We can also provide matching Posts with Clear Infill Barriers to fill-in space on the left or right sides of these turnstiles when required. All clear panels on both the turnstiles and barriers can have your logo etched as an option.

This security turnstile is highly intuitive for users and staff. Illuminated status icons on the lid and audible sounds prompt users, and provide clear notification of card acceptance or rejection.

Ask for volume pricing and request a freight quote to your location.
